DWC-XSTD05MFQ

MEGApix Ai 5MP turret IP camera with vari-focal lens, white light LEDs, flash lights and QR code reader
Features
  • 5MP sensor at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology.
  • QR code reader detects and registers codes in the FoV with green LED visual verification.
  • AI Deep Learning object detection.
  • Create up to 40 separate detection zones.
  • Easy setup with no manual analytics calibration.
  • Seamless integration and control with DW Spectrum® IPVMS.
  • Red/blue flash LEDs for an all-in-one crime deterrence solution.
  • Vari-focal p-iris lens with motorized zoom and autofocus for complete remote lens control and a focused image any time.
  • True Wide Dynamic Range (WDR) for clear images in challenging light
  • Simultaneous streaming and multiple codec options for smart bandwidth management.
  • 90’ white light illumination with intelligent camera sync for clear color images with no need for external light.
  • Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
  • Privacy zones cover sensitive areas in the camera’s field of view.
  • Two-way audio with built-in microphone and speaker for direct communication between the monitoring station and the camera’s location.
  • Local SD card slot for local recording in case of network loss.
  • Alarm sensor input and relay output for access control integration.
  • Show More

Learn about how DW
solutions can work for you

View All Markets

Ultimate all-in-one deterrent solution

DW’s turret cameras come with white light LEDs, flashing alarm lights and built in speaker and microphone, making the camera an ideal complete solution, deterring crime and recording evidence.

QR Code Reader Plugin

QR code reader detects QR codes in the camera's FoV and registers the code's text with green LED visual verification.

Deep Learning

DW’s Ai intelligent algorithms offer deep learning with better object detection and identification of environmental elements. The result is a substantial reduction in false alarms for control room operators and security personnel. Allowing only valid events to filter through increases efficiency and productivity, and reduces unnecessary costs.

White light LEDs built-in

Create deterrence and provide crystal-clear images in color without the need for external illumination or the potential loss of color and detail from B/W images.

Back-Illuminated Sensor (BIS) Technology

Backside-illumination technology flips the position of the pixels and the circuitry to collect the light from the sensor's backside. This improves light capture from 60% to over 90%.

Learn More.

Environmentally-Friendly Warm Light

The 3300 Kelvin warm White-Light provides ample lighting with no need for other sources of illumination. The warm White-Light is environmentally friendly, with minimal light pollution for residential areas while maintaining true color with no harsh discoloration in color images.

Learn More.

F1.3 Super Aperture Lens

The camera’s lens has an F1.3 wider-than-average aperture, allowing more the amount of light to enter the lens (compared to an F2.0 lens), resulting in brighter images.

Learn More.

Easy setup (no manual analytics calibration)

DW’s Ai allows operators to choose what to detect and where; with a user-friendly and straightforward UI, users can set up multiple scenarios specific to their monitoring needs without complex calibration.

Optimized Ai for the edge

MEGApix Ai's analytics engine is especially designed for the edge, working on the camera side to substantially reduce bandwidth consumption and accelerate response times.

Ambarella CV22 and CV25 chips with CVflow®

Ambarella’s CV22 and CV25 chips combine image processing, real-time 30fps 4K and 5MP video encoding and CVflow® architecture to provide the deep neural network (DNN) processing required for the next generation of intelligent IP cameras.

Ai Analytics and deep learning

DW Ai solutions include all the Intelligent Video Analytics and advanced Video Content Analysis detection capabilities of the Ai engine. In addition, Ai servers empower users with deep learning objects and people tracking and color filters.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Specifications

Color temperature Warm light, 3300K
WL wavelength (lumen) 200lm
Frequency 50Hz
Image sensor 5MP 1/2.8" CMOS sensor, Star-Light Plus™ sensor
Maximum resolution 5MP
Minimum Scene Illumination in color 0 lux (white light), 0.0 lux (B/W), 0.07 lux (color)
Total Pixels 2608(H) X 1984(V)
Lens
Advanced Lens Features Auto focus, Motorized zoom, P-iris
Focal Length 2.7 - 12mm
Horizontal Field of View (HFOV) 89.9° - 31.5°
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 64.5° - 23.6°
White Light Distance 90' range white light
I/O
Event triggers Illegal login, Motion Alarm, Network disconnection, Sensor detection, Temperature anomaly
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out 1 microphone built-in, 1 speaker built-in
Intelligent Video Analytics
Analytics filters Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Day (color)
De-fog Yes
Memory slot Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation, Email, FTP server, SD card recording
Privacy Zones 16 programmable privacy masks
QR code reader QR code support for logistics and warehouse management
Sharpness Yes
Shutter Mode Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off, x10, x2, x3, x5, x6, x7.5
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
IP IPv4
LAN RJ45 (10/100Base-T)
Network resolution H.264: 2592x1944, 2560x1440, 1920x1080, 1280x720, 800x600, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240, H.265: 2592x1944, 2560x1440, 1920x1080, 1280x720, 800x600, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240, MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
Network Web Viewer Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security 802.1x, Digest authentication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed Up to 30fps at all resolutions
Streaming Capability Triple Streaming (3rd stream MJPEG only)
Video Bitrate 100Kbps ~ 25Mbps, multi-rate for preview and recording
Video Compression Type H.264, H.265, MJPEG
Video Management Software Any ONVIF conformant CMS, DW Spectrum® IPVMS
Environmental
Compliance CE  FCC  NDAA Compliance  ONVIF  TAA Compliance  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) 4.92" x 4.79" (125 x 121.7 mm)
Camera Weight 1.94 lbs (0.88 kg)
Housing Vandal ball turret, Turret
Housing Color White
IK rating IK10 Rated
IP rating Weather Resistant (IP67)
Materials Aluminum die-casting, Polycarbonate Dome
Electrical
American wire gauge (AWG) 30M, Cable type #18
Power Consumption DC12V: 10.2W, 850mA, PoE: 12.5W, 260mA
Power Requirements Adapter not included, PoE
General
Warranty 5 Year Warranty
